For Air Conditioner

The slim upright merchandising freezer is a space-saving and efficient solution for displaying frozen goods in commercial and residential settings. With its sleek and compact design, this freezer can fit into tight spaces while still providing ample storage capacity for your frozen items. Whether you need to store frozen foods, ice cream, or other perishable goods, the slim upright freezer offers a convenient and organized solution.

• Discount


  Asynchronous Indoor Cooled Split YDK30-45 AC Fan Motor Air Conditioning

  Model:

  Ask price to be sent to your email instantly

  Send
  Add to Inquiry
• Discount


  45W Metal Fan Motor Easy Installation Fan Motor

  Model: DC-001

  Ask price to be sent to your email instantly

  Send
  Add to Inquiry
• Discount


  Metal Steel Aluminum Fan Blades | Durable Cooling Impeller For Refrigerator

  Model: NW-SD105B

  Ask price to be sent to your email instantly

  Send
  Add to Inquiry

Common Types of Air Conditioner Fan Motors

1. By Installation Location (Most Basic Classification)

Indoor Blower Fan Motors

Used inside indoor AC units to circulate cold air into rooms.

Small power, low noise, multiple adjustable speeds (low/med/high).

Mainly for split wall AC, cabinet AC, central air handlers.

Outdoor Condenser Fan Motors

Installed on outdoor units to dissipate heat from condenser coils.

High temperature resistant, waterproof sealed structure.

Single fixed speed mostly, withstand sun, rain and high ambient heat.

2. By Working Principle & Structure (Core Classification)

1) AC Asynchronous Fixed-Speed Motors (Shaded Pole / Capacitor Run Motor)

The most traditional, widely used low-cost type.

Driven by alternating current, rely on a starting capacitor to rotate.

Single fixed speed or 2–3 mechanical speed taps.

Pros: Cheap, simple structure, easy maintenance.

Cons: Low energy efficiency, high power consumption, constant loud noise.

Application: Old split AC, cheap portable air conditioners, small refrigeration equipment.

2) DC Brushless Motors (BLDC / DC Inverter Fan Motors)

Now mainstream for new energy-saving inverter air conditioners.

Powered by direct current, controlled by driver boards to adjust stepless speed.

Pros: Ultra energy-saving, quiet, wide speed regulation, long service life.

Cons: Higher cost, matched control circuit required.

Application: All modern inverter split AC, high-end cabinet AC, central air fan coils.

3) Universal Series Motors (Rare in Household AC)

Mainly used for portable small cooling fans, not standard air conditioning units.

3. Special Structural Categories

① Vertical Shaft Fan Motors

Outdoor condenser motors, vertical output shaft, fit outdoor fan blades. Fully sealed waterproof casing.

② Horizontal Shaft Blower Motors

Indoor blower motors, horizontal shaft connected to centrifugal wind wheels. Multi-speed winding design.

③ Cross-Flow Fan Special Motors

Small thin horizontal motors matching the long cross-flow wind wheel of wall-mounted indoor AC. Slim, low vibration.

④ External Rotor Motors

Motor rotor wraps around the stator; fan blades directly mounted on the outer rotor.

Compact size, large air volume. Widely used for central air fan coils and cabinet air conditioners.

⑤ Internal Rotor Motors

Traditional design: rotor inside stator. Mainly outdoor unit condenser fan motors. Simple and durable.

Quick Comparison Summary

Fixed-speed AC capacitor motor: Low cost, old model air conditioner outdoor/indoor units

BLDC brushless DC motor: Energy-saving inverter air conditioner (current mainstream)

External rotor motor: Central air, cabinet AC indoor blowers

Vertical sealed motor: Outdoor condenser heat dissipation fan motor

Cross-flow dedicated motor: Wall-mounted split AC indoor wind wheel
