Fin Evaporator

Our fin type condenser is an air-cooled heat exchanger for refrigeration and air conditioning equipment. Made of high thermal conductivity copper tubes and dense aluminum fins, it creates a large heat dissipation area for fast heat exchange. Compact in size, stable in operation, energy-saving and anti-rust, it fits cold storage units, air conditioners and small refrigeration machines perfectly, bringing consistent cooling performance with simple installation.

• Discount


  Industrial Copper Tube Customized Fin Refrigeration

  Model: Fin-1

  Ask price to be sent to your email instantly

  Send
  Add to Inquiry

Product & Material Q&A

Q1: What material is your fin type condenser made of?

A1: We adopt seamless inner-grooved copper tubes for good heat conductivity and anti-leak performance, matched with louver aluminum fins. Optional hydrophilic blue coating fins for humid environment, bare silver fins for dry workshop use. Frame is galvanized steel to prevent rust.

Q2: What tube diameters do you support?

A2: Standard sizes: 7mm, 7.94mm, 9.52mm, 12.7mm, 15.88mm. Custom tube size and row count are acceptable.

Q3: What refrigerants can this condenser work with?

A3: Compatible with R134a, R22, R404A, R410A, R507 and most common freon refrigerants for commercial refrigeration & HVAC.

Application & Performance Q&A

Q4: Where can fin type condensers be applied?

A4: Widely used for cold storage units, air conditioners, freezers, ice machines, condensing units, heat pumps and small industrial cooling equipment.

Q5: Why is fin type condenser more efficient than traditional coil condenser?

A5: Louver fins expand heat exchange area greatly and disturb air flow to cut thermal resistance, which improves cooling efficiency by 25%-35% and lowers compressor energy consumption. Compact structure saves installation space.

Q6: Can it work outdoors under high temperature?

A6: Yes. All coils pass anti-corrosion treatment. It can stably run under ambient temperature up to 45℃, suitable for outdoor cold room and rooftop air conditioning units.

Customization & Order Q&A

Q7: Do you support OEM & customized size?

A7: Fully customizable. We adjust length, width, fin spacing, air outlet direction (top blow / side blow), tube rows and mounting frame according to your equipment drawings. OEM logo and carton packaging are available.

Q8: What’s your MOQ?

A8: MOQ is 1 piece for standard models; bulk order discount for over 50 units. Fast production within 7-15 working days.

Q9: Can you match fan assembly together with condenser coil?

A9: Yes, we can supply complete condenser unit with axial fans, EC fans or AC fans as customer request.
